From Excel Spreadsheets to Digital Measurement Equipment Management – Why ISO 17025 Demands More
From Excel spreadsheets to digital test equipment management – why ISO 17025 demands more
Many testing and calibration laboratories still use Excel spreadsheets or paper-based systems to manage their test equipment. At first glance, this seems pragmatic: spreadsheets are quick to create, easy to adapt, and already established in many organizations.
However, in the long run, this approach clashes with the requirements of DIN EN ISO 17025 and DIN ISO IEC 17025. The limitations become apparent at the latest when the number of measuring instruments increases or multiple locations are involved. Furthermore, the problem is exacerbated by a generational shift among auditors: younger auditors interpret ISO 17025 more precisely and consistently. Laboratories should prepare for increasingly stringent audits – Excel will no longer meet these requirements.
The consequences range from a lack of traceability and unclear calibration intervals to serious risks for audit compliance and accreditation. This is precisely where modern solutions such as specialized test equipment management software come into play – for example, laboratory software like LabThunder.
[[image-1]]
Standard context: What DIN EN ISO/IEC 17025 specifically requires
ISO 17025 governs the competence of testing and calibration laboratories. Three sections are particularly relevant for test equipment management, measuring equipment management, and measuring equipment monitoring:
§ 6.4 – Equipment
Laboratories must ensure that all testing and measuring equipment is suitable for its intended purpose. Each piece of equipment requires a unique identifier, including its calibration and maintenance data. Furthermore, complete records of calibration, adjustment, maintenance, repair, and condition must be maintained.
§ 6.6 – Externally Provided Products and Services
If calibrations are outsourced, laboratories must ensure that the service provider meets the requirements – for example, through accreditation. The traceability of the standards and calibration chains used must be documented.
§ 7.11 – Data and Information Management
Collected measurement data and metadata must be protected against loss, manipulation, and unauthorized modification. Changes to data must be traceable – through change tracking and a complete audit trail. This explicitly applies to electronically maintained records such as Excel spreadsheets, Access databases, or other custom systems.
Standards-compliant test equipment management is therefore more than just an inventory list. It involves structured test equipment monitoring and a robust system for ensuring audit compliance.
Overview of responsibilities: What a laboratory must provide organizationally
An ISO 17025-compliant system for test equipment management and measuring equipment management must cover the following areas:
Unique identification
Each piece of testing equipment is assigned a unique testing equipment number. The risk of confusion due to duplicate or outdated numbers must be eliminated.
Calibration and measuring instrument monitoring
Calibration intervals must be defined and documented – based on risk, frequency of use, and manufacturer specifications. Monitoring measuring equipment requires clear due dates, reminders, and a blocking mechanism for overdue calibrations. Calibration certificates and test certificates must be assigned and readily available.
Traceability
Traceability to national or international standards must be ensured. The standards used, calibration laboratories, and relevant parameters must be documented.
Maintenance and servicing
Preventive maintenance and repairs must be planned and documented. The status of the testing equipment – for example, in case of defects or shutdowns – must be clearly linked.
Status indicator
Every testing or measuring instrument must clearly indicate its status: calibrated/released, locked/out of service, or undergoing calibration/maintenance.
These requirements can theoretically be mapped in Excel – in practice, many laboratories fail to implement them consistently and without errors.
Audit reality: Typical mistakes in practice
Similar problems repeatedly arise in audits according to DIN EN ISO 17025 or DIN ISO IEC 17025:
- Duplicate test equipment numbersin different Excel files or versions
- Missing or incorrect calibration intervals, because changes were discussed but not reflected in the table
- Missing calibration certificates, which are located locally or in email mailboxes
- Outdated stockLong-discontinued testing equipment still appears in the list.
- Non-transparent changesRegarding Excel files: No one can trace who edited which data and when.
- Overdue calibrations, because no automatic test equipment monitoring exists
Such deviations not only jeopardize audit compliance, but in the worst case also the validity of test and measurement results.
Why Excel fails in the long run
Excel was not designed for standards-critical test equipment management. Its weaknesses are evident in four key areas:
1. Data integrity
Files can be accidentally overwritten, corrupted, or stored locally. Versions in different departments diverge. There is no built-in logic to reliably enforce required fields, plausibility checks, or blocking rules.
2. Change tracking
A true audit trail is lacking. Changes can only be traced with considerable additional effort. However, ISO 17025 requires that data changes be documented and traceable.
3. Calibration deadlines and reminders
Due dates must be manually maintained and monitored. As the number of test instruments increases, the list becomes unwieldy. Escalation mechanisms, such as automatic blocking of overdue measuring instruments, are lacking.
4. Multi-site and multi-user capability
Parallel access to an Excel file quickly leads to conflicts or inconsistencies. Different teams – such as testing, calibration, and quality management departments – do not have a shared, reliable data set.
Excel can help temporarily, but it cannot be used to implement digital test equipment management in accordance with ISO 17025 in a sustainable, secure and audit-proof manner.
Digitalization as a solution: What test equipment management software can do
Modern test equipment management software or test equipment monitoring software addresses precisely these weaknesses and creates a central, standards-compliant database.
Automated test equipment monitoring
Centralized master data for all testing and measuring equipment enables automatic calculation of calibration deadlines and notifications when they are due. Status changes – such as blocking due to overdue calibrations – are rule-based.
Full audit trail
Every change to master data for test equipment, calibration or maintenance information is logged. Responsibilities are clearly traceable – a key aspect of audit compliance.
Integrated document management
Calibration certificates and other documentation are stored directly with the test equipment. This allows for quick access during audits, eliminating the need for time-consuming searches through folder structures or emails.
Unified measuring instrument management
A uniform structure for testing and measuring equipment across all laboratories and locations, combined with clear role and rights assignment for laboratory management, quality management, technology and purchasing.
Integrated laboratory software combines test equipment management, test equipment monitoring, and other laboratory processes such as maintenance planning, logbook, and documentation. This creates a consistent, digital representation of laboratory reality – the basis for efficient processes and secure accreditations.
Practical example: From Excel chaos to ISO 17025 compliance
A medium-sized testing and calibration laboratory with around 400 active test instruments worked for years with several Excel spreadsheets. Each department maintained its own instrument management system, sometimes in different formats.
The following problems were revealed during a surveillance audit:
- Several test instruments with overdue calibration because due dates had been adjusted in an older Excel version but not transferred.
- A calibration certificate for a critical reference standard could not be found.
- Two devices bore the same test equipment number – one in the main laboratory, one in a branch office.
The result: deviations in the audit, extensive rework and increased pressure on quality management and laboratory management.
The laboratory decided to switch to test equipment monitoring software and implemented LabThunder as its central platform:
- All testing equipment was migrated in a structured manner and assigned unique IDs.
- Calibration intervals, responsible parties and service providers were centrally stored.
- LabThunder took over calibration monitoring with automatic reminders
- Calibration certificates were stored as PDFs directly with the respective test equipment.
- The integrated audit trail has been logging every change ever since.
In the next surveillance audit, the laboratory was able to demonstrate at the touch of a button which testing equipment was used for which procedures, when it was last calibrated, and that all relevant documents were complete. The auditors particularly emphasized the clear traceability and consistent management of testing equipment.
Conclusion: Without digital test equipment management, ISO 17025 becomes a risk.
Anyone who takes the requirements of DIN EN ISO 17025 or DIN ISO IEC 17025 seriously will eventually need systematic, digital test equipment management. Excel spreadsheets and manual workarounds may work in the short term, but ultimately fail for the following reasons:
- Data integrity and traceability
- Continuous monitoring of test equipment
- Transparent change tracking
- Multi-site and multi-user capability
Specialized test equipment management software ensures that calibration, maintenance, traceability and status marking are implemented in accordance with standards and are audit-proof – and sustainably relieves the burden on laboratory management and QM.
LabThunder for audit-compliant, digital test equipment management
If you want to make your test equipment management, measuring equipment management and test equipment monitoring future-proof and ISO-17025 compliant, now is the right time to switch to a digital solution.
LabThunder offers you:
- Centralized, digital test equipment management for all devices and measuring instruments
- Automated calibration and maintenance reminders
- Complete audit trail and secure traceability
- Integrated laboratory software for logbook, maintenance, knowledge management and more
Learn more about how LabThunder supports your laboratory in complying with ISO 17025 and sustainably digitizes your processes.
Frequently Asked Questions About ISO 17025 and Measurement Equipment Management
Is Excel permissible for ISO 17025 test equipment management?
Theoretically yes, but practically unsuitable. Excel can meet the formal requirements of the standard, but usually falls short on data integrity, change tracking, and multi-user capability. Modern auditors are increasingly critical of Excel-based solutions, since a genuine audit trail is lacking and version conflicts are hard to trace. As the number of pieces of test equipment or sites grows, Excel lists reach their limits sooner rather than later.
What does ISO 17025 require for test equipment management?
ISO 17025 requires the unique identification of all testing equipment, comprehensive documentation of calibrations and maintenance, and traceability to national standards. Furthermore, a complete audit trail must be maintained for all data modifications. The relevant sections are § 6.4 (Equipment), § 6.6 (Externally provided products and services), and § 7.11 (Control of data and information management).
What is the difference between a test instrument and a measuring instrument?
Test aids serve qualitative assessment, such as gauges, test fixtures, or inspection templates. Measuring instruments provide quantitative measured values, for example scales, calipers, or thermometers. ISO 17025 treats both under the term "equipment" and places the same requirements on identification, calibration, and documentation.
What happens during an audit if calibration is overdue?
Overdue calibrations are classified as major non-conformities during audits. If measurements or tests have been performed using overdue equipment, the worst-case scenario is the revocation of accreditation for the affected procedures. The laboratory must re-evaluate all affected measurement results and, if necessary, inform customers. Systematic delays indicate deficiencies in the management system.
How often must measuring equipment be calibrated according to ISO 17025?
ISO 17025 does not mandate fixed calibration intervals. Laboratories must determine these intervals based on risk, taking into account frequency of use, manufacturer specifications, historical drift, and the impact on measurement results. It is essential that these determinations are documented and justified. Shorter intervals may be necessary for critical measuring equipment.
Can I lose my accreditation due to deficiencies in testing equipment?
Yes, that is possible. Serious deficiencies such as a lack of traceability, systematically overdue calibrations, or a missing audit trail can lead to the suspension or withdrawal of accreditation. It becomes particularly critical if it is proven that faulty testing equipment has led to incorrect measurement results. In such cases, laboratories must demonstrate extensive corrective measures and, if necessary, inform their customers.
What is an audit trail in test equipment management?
ISO/IEC 17025 does not explicitly require an "audit trail." However, section 7.11 (Control of data and information management) stipulates that laboratory and test data must be protected, traceable, and secured against unintended or unauthorized alteration. An audit trail is therefore a proven method for meeting these requirements—though it is not a strictly mandated feature.
Are ISO 17025 audits becoming stricter?
Yes, this trend is clearly visible. A generational shift among auditors is leading to a more precise interpretation of ISO 17025. Younger auditors have grown up with digital standards and examine data integrity, audit trails, and calibration monitoring much more rigorously than their predecessors. Laboratories should be prepared for the fact that manual or Excel-based solutions are increasingly being scrutinized.
How long does it take to switch to digital gauge management?
Typically, the transition takes between two and six weeks. Data migration from Excel spreadsheets requires one to two weeks, while software configuration takes three to five days. In addition, there is one to two days of training and one to two weeks of parallel operation to ensure a smooth transition. For laboratories with 100 to 500 pieces of test equipment, a timeframe of about four weeks is realistic. Larger laboratories or those with complex site structures may require more time.
Must every piece of test equipment have a unique number?
Yes, this is mandatory. Section 6.4.3 of ISO 17025 requires unique identification for each piece of test and measurement equipment. Duplicate or ambiguous numbers regularly lead to audit nonconformities. The identification must be permanently affixed to the device and rule out any possibility of confusion. Even decommissioned devices must not have their numbers reassigned.
Which software is suitable for ISO 17025 equipment management?
Effective test equipment management software must offer several core functions: unique IDs for all devices, automatic calibration reminders, a complete audit trail, integrated document management for calibration certificates, status management with a locking function, and differentiated access rights. Specialized solutions such as LabThunder or certain LIMS systems with a test equipment module meet these requirements. Cloud- or server-based systems also enable multi-site usage.
